PARAMETERS
|
Supply out
|
12v 3A |
| Operating Temperature Range |
-30°C to 80°C |
| Phase wires |
7.0kg / 180mm |
| Battery wires |
8AWG terminals M6 |
| Control modes |
Square, sensorless, FOC, charger |
Protection
|
Temperature and hardware overcurrent protection |
|
| Sleep current less |
<300uA |
| Protection class |
IP54 filled with IP67 COMPOUND.
|
| Size, without wires |
86х43х185 mm |
| Weight |
1100 g
|
| FEATURES |
| LCD size 3.6" |
FSTN, monochrome |
| Screen resolution 240x128 px |
Screen heating |
| RGB-button backlight |
MicroSD slot |
| USB-charger 5.2V 2А |
Password protection |
| Rated Rotation Speed |
4300rpm |
| Peak Efficiency |
97.8% |
| Multilanguage (English, Russian) |
IP65 class (IP67 with compound) |
|
|
|
| ADVANCED FEATURES |
|
ARM Cortex M4 CPU and 10 000hr 105C Low-ESR capacitors |
|
Voltage monitoring on all motor phases, power supply, system supply 12V, and 5V |
|
Synchronous rectification, ultra low drop, fast PWM to achieve very high efficiency |
|
|
Direct phase current sense and hardware over current protection |
|
Electric brake different modes available |
|
Configurable limit for motor and battery current |
|
Battery protection: over current, over-voltage and under-voltage protection |
|
Motor and controller temperature protection |
|
Support motors with any number of poles |
|
Up to 100,000 electric RPM (ERPM = Pole pair * RPM) |
|
Auto-detect 60 degrees or 120-degree hall position sensors |
|
Support torque mode, speed mode, and combined operation, instant throttle response, no lag |
|
|
Aluminum housing for maximum heat dissipation, dual side FET for best heat distribution |
|
Wide types of input, configurable: 0-5V brake, switch brake, 0-5V throttle, torque pedal sensor, pedal-assist sensor
|
|
Configurable from Display
|
|
|
Auto no-operation shut down |
|
|
Various modes of control: sensorless, square, combined, FOC |
|
|
Multiple controllers on CAN bus may exist (open protocol LEVCAN)
|
|
Forged by 6000 Tons of Pressure |
|
Charge mode through the motor with the controller, plug any DC supply to the controller to charge your battery |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
